Paper X, XX, XXX Paper Reinforced Phenolic

paper phenolic tubes

Paper X/XX/XXX Paper Reinforced Phenolic - natural (tan)

Technical Data Sheet

Chemical Resistance Chart


Composed of a paper base impregnated with a phenolic resin binder. It has good electric strength properties with fair mechanical strength. Outstanding for use as template material and or backup material.

Certifies to

X MIL-I-24768/12 PBM, IEC 60893-3 Type 4 PF CP 201
XX MIL-I-24768/11 PBG, IEC 60893-3 Type 4 PF CP 203
XXX MIL-I-24768/10 PBE, IEC 60893-3 Type 4 PF CP 201

NEMA grades X, XX and XXX Paper Reinforced Phenolic -- natural color is typically light tan to brown. These grades are composed of a paper base impregnated with a phenolic resin binder. (Phenolics are the oldest, best-known general purpose thermoset resins. They are among the lowest in cost and easiest to process. Phenolics are quite adequate for a fair percentage of electrical applications. Generally speaking, they are not equivalent to epoxies in resistance to moisture, humidity, dimensional stability, shrinkage and retention of electrical properties in extreme environments.) The paper reinforced phenolic has good electric strength properties with fair mechanical strength and are outstanding for use as template material and/or back-up material.

Click Here for X, XX, XXX      Tubes or Sheets Bar



X, XX, XXX Paper Reinforced Rods
Stock # Diameter Inches Price/Ft. Purchase Online
KR-1289

.062"

$1.22 Buy Now
KR-1290

.093"

$1.10 Buy Now
KR-1291

.125"

$1.14 Buy Now
KR-1292

.156"

$1.26 Buy Now
KR-1293

.187"

$1.44 Buy Now
KR-1294

.250"

$1.80 Buy Now
KR-1295

.312"

$2.20 Buy Now
KR-1296

.375"

$2.46 Buy Now
KR-1297

.437"

$3.18 Buy Now
KR-1298

.500"

$4.02 Buy Now
KR-1299

.562"

$4.70 Buy Now
KR-1300

.625"

$5.38 Buy Now
KR-1301

.750"

$7.18 Buy Now
KR-3159

.875"

$9.16 Buy Now
KR-1302

1.000"

$11.74 Buy Now
KR-1303

1.125"

$14.30 Buy Now
KR-1304

1.250"

$16.56 Buy Now
KR-1305

1.375"

$19.56 Buy Now
KR-1306

1.500"

$23.02 Buy Now
KR-1307

1.625"

$26.00 Buy Now
KR-1308

1.750"

$31.72 Buy Now
KR-1309

2.000"

$43.96 Buy Now
Tolerances

Under 1.375" Dia.

+ / -.001"

1.375" Dia. & Over

+ / -.003"



X, XX, XXX Paper Reinforced Sheets & Plates
Stock # Thickness Inches Width Inches Length Inches  Price Purchase Online
KS-5942 .031 12 12  $1.85   Buy Now
KS-2128 .063 12 12  $2.98 Buy Now
KS-2135 .094 12 12  $4.47 Buy Now
KS-2142 .125 12 12  $5.81 Buy Now
KS-2149 .188 12 12  $8.70 Buy Now
KS-2156 .250 12 12  $11.68 Buy Now
KS-2163 .313 12 12  $14.58 Buy Now
KS-2170 .375 12 12  $27.54 Buy Now
KS-2177 .500 12 12  $36.70 Buy Now
KS-2184 .625 12 12  $45.88 Buy Now
KS-2191 .750 12 12  $55.06 Buy Now
KS-2198 1.000 12 12  $73.42 Buy Now
KS-2205 1.250 12 12  $91.78 Buy Now
KS-2212 1.500 12 12  $110.12 Buy Now
KS-2219 2.000 12 12  $146.84 Buy Now
KS-5943 .031 12 24  $3.70   Buy Now
KS-2129 .063 12 24  $5.95 Buy Now
KS-2136 .094 12 24  $8.94 Buy Now
KS-2143 .125 12 24  $11.61 Buy Now
KS-2150 .188 12 24  $17.40 Buy Now
KS-2157 .250 12 24  $23.36 Buy Now
KS-2164 .313 12 24  $29.16 Buy Now
KS-2171 .375 12 24  $55.08 Buy Now
KS-2178 .500 12 24  $73.40 Buy Now
KS-2185 .625 12 24  $91.76 Buy Now
KS-2192 .750 12 24 $110.12 Buy Now
KS-2199 1.000 12 24 $146.84 Buy Now
KS-2206 1.250 12 24 $183.56 Buy Now
KS-2213 1.500 12 24 $220.24 Buy Now
KS-2220 2.000 12 24 $293.68 Buy Now
KS-2130 .063 12 36 $8.93 Buy Now
KS-2137 .094 12 36 $13.42 Buy Now
KS-2151 .188 12 36 $17.42 Buy Now
KS-2158 .250 12 36 $26.11 Buy Now
KS-2165 .313 12 36 $35.04 Buy Now
KS-2172 .375 12 36 $43.74 Buy Now
KS-2179 .500 12 36 $110.10 Buy Now
KS-2186 .625 12 36 $137.64 Buy Now
KS-2193 .750 12 36 $165.18 Buy Now
KS-2200 1.000 12 36 $220.26 Buy Now
KS-2207 1.250 12 36 $275.34 Buy Now
KS-2214 1.500 12 36 $330.36 Buy Now
KS-2131 .063 12 48 $11.90 Buy Now
KS-2138 .094 12 48 $17.89 Buy Now
KS-2152 .188 12 48 $23.23 Buy Now
KS-2159 .250 12 48 $34.81 Buy Now
KS-2166 .313 12 48 $58.31 Buy Now
KS-2173 .375 12 48 $110.16 Buy Now
KS-2180 .500 12 48 $146.80 Buy Now
KS-2187 .625 12 48 $183.52 Buy Now
KS-2194 .750 12 48 $220.24 Buy Now
KS-2201 1.000 12 48 $293.68 Buy Now
KS-2208 1.250 12 48 $367.12 Buy Now
KS-2215 1.500 12 48 $440.48 Buy Now
KS-2221 2.000 12 48 $587.36 Buy Now
KS-5944 .031 24 24  $7.39   Buy Now
KS-2132 .063 24 24 $11.90 Buy Now
KS-2139 .094 24 24 $17.89 Buy Now
KS-2146 .125 24 24 $23.23 Buy Now
KS-2153 .188 24 24 $34.81 Buy Now
KS-2160 .250 24 24 $46.72 Buy Now
KS-2167 .313 24 24 $58.31 Buy Now
KS-2174 .375 24 24 $110.16 Buy Now
KS-2181 .500 24 24 $146.80 Buy Now
KS-2188 .625 24 24 $183.52 Buy Now
KS-2195 .750 24 24 $220.24 Buy Now
KS-2202 1.000 24 24 $293.68 Buy Now
KS-2209 1.250 24 24 $367.12 Buy Now
KS-2216 1.500 24 24 $440.48 Buy Now
KS-5945 .031 24 36  $11.09   Buy Now
KS-2133 .063 24 36 $17.85 Buy Now
KS-2140 .094 24 36 $26.83 Buy Now
KS-2147 .125 24 36 $34.84 Buy Now
KS-2154 .188 24 36 $52.21 Buy Now
KS-2161 .250 24 36 $70.08 Buy Now
KS-2168 .313 24 36 $87.47 Buy Now
KS-2175 .375 24 36 $165.24 Buy Now
KS-2182 .500 24 36 $220.20 Buy Now
KS-2189 .625 24 36 $275.28 Buy Now
KS-2196 .750 24 36 $330.36 Buy Now
KS-2203 1.000 24 36 $440.52 Buy Now
KS-2210 1.250 24 36 $550.68 Buy Now
KS-2217 1.500 24 36 $660.72 Buy Now
KS-2134 .063 24 48 $23.80 Buy Now
KS-2141 .094 24 48 $35.77 Buy Now
KS-2148 .125 24 48 $46.45 Buy Now
KS-2155 .188 24 48 $69.61 Buy Now
KS-2162 .250 24 48 $93.44 Buy Now
KS-2169 .313 24 48 $116.63 Buy Now
KS-2176 .375 24 48 $220.32 Buy Now
KS-2183 .500 24 48 $293.60 Buy Now
KS-2190 .625 24 48 $367.04 Buy Now
KS-2197 .750 24 48 $440.48 Buy Now
KS-2204 1.000 24 48 $587.36 Buy Now
KS-2211 1.250 24 48 $734.24 Buy Now
KS-2218 1.500 24 48 $880.96 Buy Now
KS-5715 .031 36 48 $22.18   Buy Now
KS-5716 .047 36 48 $28.88   Buy Now
KS-5718 .062 36 48 $35.70   Buy Now
KS-17992 .078 36 48 $44.68 *
KS-6017 .093 36 48 $53.66 .Buy Now
KS-5946 .125 36 48 $69.68 .Buy Now
KS-6018 .156 36 48 $87.06 .Buy Now
KS-5947 .188 36 48 $104.42 .Buy Now
KS-5948 .250 36 48 $140.16 .Buy Now
KS-6019 .313 36 48 $174.94 .Buy Now
KS-5949 .375 36 48 $210.26 .Buy Now
KS-6020 .437 36 48 $245.00 .Buy Now
KS-5950 .500 36 48 $280.32 .Buy Now
KS-17996 .562 36 48 $315.08 *
KS-4035 .625 36 48 $350.40 .Buy Now
KS-4038 .750 36 48 $420.48 .Buy Now
KS-6021 .875 36 48 $490.56 .Buy Now
KS-5951 1.00 36 48 $560.66 .Buy Now
KS-17994 1.125 36 48 $630.74 *
KS-5952 1.25 36 48 $700.82 .Buy Now
KS-17993 1.375 36 48 $770.88 *
KS-5953 1.50 36 48 $840.96 .Buy Now
KS-6023 1.75 36 48 $981.14 .Buy Now
KS-6024 2.00 36 48  $1121.30 .Buy Now


Tolerances for Sheet Thickness Inches

.020-.030 + / -.004" .093+ / -.009" .250+ / -.022" .500+ / -.036" .875+ / -.046" 1.50+ / -.061"
.031  + / -.005" .125+ / -.012" .313+ / -.026" .625+ / -.040" 1.00+ / -.046" 1.75+ / -.065"
.062 + / -.0085" .188+ / -.019" .375+ / -.030" .750+ / -.043" 1.25+ / -.049" 2.00+ / -.069"
